APPENDIX A. CONNECTOR PIN DEFINITIONS
The following tables provide the pin assignments for the base units, network interface modules (NIMs),
and dial backup interface modules (DIMs).
Base Unit Pinouts
Table A-1. 10/100BaseT Ethernet Port Pinouts
Pin Name Description
1 TX1 Transmit Positive (PoE negative rail, switch ports only)
2 TX2 Transmit Negative (PoE negative rail, switch ports only)
3 RX1 Receive Positive (PoE negative rail, switch ports only)
4, 5 — Unused
6 RX2 Receive Negative (PoE negative rail, switch ports only)
7, 8 — Unused
Table A-2. CONSOLE Port (DCE) Pinouts for NetVanta 3200, 3205, 3430, and 3448
Pin Name Description
1 DCD Data Carrier Detect (output)
2 RD Receive Data (output)
3 TD Transmit Data (input)
4 DTR Data Terminal Ready (input)
5 SG Signal Ground
6 DSR Data Set Ready (output) Tied to pin 1
7 — Unused
8 CTS Clear to Send (output) Tied to pin 1
9 — Unused
