Unit Installation NetVanta 3000 Series Hardware Installation Guide
66 Copyright © 2006 ADTRAN, Inc. 61200860L1-34L
Supplying Power to the Unit
As shipped, each NetVanta 3000 Series is set to factory default conditions. After installing the base unit
and any option modules, the NetVanta 3000 Series is ready to be powered up. To power the unit, ensure
that the unit is properly connected to an appropriate power source (as outlined in the sections which
follow).
NetVanta 3120 and NetVanta 3130
The NetVanta 3120 and NetVanta 3130 come equipped with a 12 VDC power supply for connecting to the
proper power receptacles.
NetVanta 3200
The AC-powered NetVanta 3200 comes equipped with the appropriate power supply for connecting to the
proper power receptacles.
NetVanta 3205 (AC), NetVanta 3305, NetVanta 3430, and NetVanta 3448
The AC-powered NetVanta 3205, NetVanta 3305, NetVanta 3430, and NetVanta 3448 come equipped with
an auto-sensing 100 to 240 VAC, 50/60 Hz power supply for connecting to the proper power receptacle. A
grounded, three-plug detachable cable is included with the shipment.
• This unit shall be installed in accordance with Articles 300 and 400 of NEC NFPA 70.
• Maximum recommended ambient operating temperature is 50
o
C.
• This unit shall be installed in accordance with Articles 300 and 400 of NEC NFPA 70.
• Power to the AC system must be from a grounded 100 to 250 VAC, 50/60 Hz source.
• Maximum recommended ambient operating temperature is 50
o
C.
