NetVanta 3000 Series Hardware Installation Guide OVERVIEW
61200860L1-34L Copyright © 2006 ADTRAN, Inc. 37
NetVanta 3430 Rear Panel Interfaces
SLOT 1 NET/DBU Option Slot
The SLOT 1 NET/DBU option slot supports various NIM plug-in option modules. These option
modules are described in the section Option Modules on page 43.
10/100BaseT Ethernet Interfaces
The Ethernet ports (ETH 0/1 and ETH0/2) are RJ-45 connectors. These ports provide the following:
• 10BaseT or 100BaseT with a single connector
• Auto-negotiation
•CSMA/CD
• IEEE 802.3 compatibility
CONSOLE Interface
The CONSOLE interface is an EIA-232 serial port (DCE) which provides for local management and
configuration (via a DB-9 female connector).
Power Connection
All of the 1U-high products have universal power supplies and are shipped with the appropriate cable.
Please refer to Supplying Power to the Unit on page 66 for connection details.
NetVanta 3448
The NetVanta 3448 is a high-performance modular access router designed for cost-effective branch office
connectivity over MPLS, Frame Relay, multilink Frame Relay, point-to-point (PPP), multilink PPP, or
Ethernet networks. It offers an integrated 8-port fully-managed Ethernet switch. The switch ports can
optionally be equipped to provide (802.3af/Legacy) Power Over Ethernet capability.
This section includes a list of features, a list of shipping contents, and a description of the unit’s front and
rear panel designs. For hardware installation topics such as mounting the unit, installing option cards, and
installing the optional SODIMM, refer to the following sections:
• Mounting Options on page 63
• Supplying Power to the Unit on page 66
• Installing Dial Backup and Network Interface Modules on page 68
• Installing a SODIMM for Expandable Memory on page 71
For information on router configuration for a specific application, refer to the quick configuration
documents provided on your ADTRAN OS System Documentation CD. For details on the command line
interface, refer to the AOS Command Reference Guide (also included on your CD).
Connection directly to an external modem requires a cross-over cable.
