Osmo1™ Single-Sample Micro-Osmometer Service Guide
Chapter 5
Settings
The chapter describes how to access and confi gure the
instrument settings.
5.1 Accessing the Settings menu
The Settings menu (Figure 23) provides access to the
functions listed in Table 6.
Function Description/Use
Date & Time Set date and time and specify format.
Language Set user interface language.
Users Add, edit, and delete user accounts.
H/W Options Set audio tone and volume;
Adjust screen brightness;
Enable/disable printer;
Adjust barcode scanner settings.
Probe Resistance Enter/change probe resistance.
Controls Add, edit, and delete controls;
Display a Levey-Jennings chart;
Add an action to a control.
LIS/LAN Confi gure LIS, enter IP address, ping.
Service Access utilities related to system
updates, system resets, troubleshooting,
and database management.
Restrictions Set operator-level access;
Set password expiration period;
Change number of calibration points;
Enable/disable requirement to enter
the User ID and Sample ID for testing.
Table 6: Functions available from the Settings menu
To access the Settings menu:
1. From the Home screen, tap the menu icon
(Figure 21).
Figure 21: Menu icon
The Main menu displays (Figure 22).
Figure 22: Osmo1 Main menu
2. From the Main menu, tap Settings.
The Settings menu displays (Figure 23).
Figure 23: Settings menu
From the Settings menu, you can tap a button to select a
particular function (described in the following sections),
or you can tap the Home button to return to the Home
screen.
NOTE: Access to a function is indicated by key color on
the button surround (Figure 24):
• Gold: Restricted to Supervisor access only
• White: Operator and supervisor access allowed
Figure 24: Key colors
