ADAM-6100PN User Manual 44
A.1 Analog Input and Analog Output Modules
Each ADAM-6100 analog module will use up to 8 WORD address for its data. Each
analog channel will occupy one WORD address.
ADAM-6117 Name Data Type Data Format
Input AI Channel 0 Unsigned 16 Bit [15…0]
AI Channel 1 Unsigned 16 Bit [15…0]
AI Channel 2 Unsigned 16 Bit [15…0]
AI Channel 3 Unsigned 16 Bit [15…0]
AI Channel 4 Unsigned 16 Bit [15…0]
AI Channel 5 Unsigned 16 Bit [15…0]
AI Channel 6 Unsigned 16 Bit [15…0]
AI Channel 7 Unsigned 16 Bit [15…0]
ADAM-6118 Name Data Type Data Format
Input AI Channel 0 Unsigned 16 Bit [15…0]
AI Channel 1 Unsigned 16 Bit [15…0]
AI Channel 2 Unsigned 16 Bit [15…0]
AI Channel 3 Unsigned 16 Bit [15…0]
AI Channel 4 Unsigned 16 Bit [15…0]
AI Channel 5 Unsigned 16 Bit [15…0]
AI Channel 6 Unsigned 16 Bit [15…0]
CJC Channel Unsigned 16 Bit [15…0]
ADAM-6124 Name Data Type Data Format
Input DI Channel 0...3 Unsigned 8 Bit [3…0]
Output AO Channel 0 Unsigned 16 Bit [15…0]
AO Channel 1 Unsigned 16 Bit [15…0]
AO Channel 2 Unsigned 16 Bit [15…0]
AO Channel 3 Unsigned 16 Bit [15…0]
