Advantech ADAM-6156PN User Manual

45 ADAM-6100PN User Manual
Appendix A PROFINET Mapping Table
A.2 Digital Input and Digital Output Modules
Each ADAM-6100 digital module will use up to 2 BYTE address for its data. Each
BYTE address will contain 8 digital channel data.
ADAM‐6150 Name DataType DataFormat
Input DIChannel0...7 Unsigned8Bit[7…0]
Output DOChannel0...6 Unsigned8Bit[6…0]
ADAM‐6151 Name DataType DataFormat
Input
DIChannel0...7 Unsigned8Bit[7…0]
DIChannel8...15 Unsigned8Bit[7…0]
ADAM‐6156 Name DataType DataFormat
Output
DOChannel0...7 Unsigned8Bit[7…0]
DOChannel8...15 Unsigned8Bit[7…0]
ADAM‐6160 Name DataType DataFormat
Output DOChannel0...5 Unsigned8Bit[5…0]
