AIMB-252 User Manual 6
Internal
Connector
LVDS & Inverter 2
USB 4 (USB 2.0 compliant)
Serial 4 (RS-232)
IDE 1
SATA 2
Compact Falsh 1
IrDA -
DIO 16-bit GPIO
Watchdog
Timer
Output Interrupt, system reset
Interval Programmable 1 ~ 255 sec/ min
Power
Requirement
Typical Intel 915GME and Pentium M 760 2.0 GHz FSB 533 MHz,
2 GB DDR2 SDRAM
+5 V +3.3 V +12 V +5 V
SB
2.61 A 0.71 A 1.93 A 0.59 A
Environment
Operating
Temperature 0 ~ 60° C (32 ~ 140° F)
Physical
Characteristics
Dimensions 170 mm x 170 mm
(6.69" x 6.69")
* Intel 910GMLE only supports FSB 400 processor and DDR2 400 SDRAM
