81 AIMB-252 User Manual
Appendix B Pin Assignments
B.17 LVDS Connector (LVDS1/LVDS2)
Table B.18: LVDS Connector (LVDS1/2)
Pin Signal Pin Signal
1 VDDSAFE_1 21 VDDSAFE_2
2 GND_1 22 GND_7
3 VDDSAFE_3 23 VDDSAFE_4
4OD0- 24ED0-
5OD0+ 25ED0+
6 GND_2 26 GND_8
7OD1- 27ED1-
8OD1+ 28ED1+
9 GND_3 29 GND_9
10 OD2- 30 ED2-
11 OD2+ 31 ED2+
12 GND_4 32 GND_10
13 OCK- 33 ECK-
14 OCK+ 34 ECK+
15 GND_5 35 GND_11
16 DDC_CLK 36 DDC_DAT
17 GND_6 37 GND_12
18 OD3- 38 ED3-
19 OD3+ 39 ED3+
20 HPLG 40 VCON
2
438
40
3
1
37
39
