Advantech AIMB-252 - Serial Port Connector 23 (COM23); Serial Port Connector 45 (COM45)

AIMB-252 User Manual 24
1.14.4 Serial Port Connector 23 (COM23)
1.14.5 Serial Port Connector 45 (COM45)
DDCD2_N
RRXD2
TTXD2
DDTR2_N
GND
DDCD3_N
RRXD3
TTXD3
DDTR3_N
GND
DDSR2_N
RRTS2_N
CCTS2_N
RRI2_M
GND
DDSR3_N
RRTS3_N
CCTS3_N
RRI3_N
GND
DDCD4_N
RRXD4
TTXD4
DDTR4_N
GND
DDCD5_N
RRXD5
TTXD5
DDTR5_N
GND
DDSR4_N
RRTS4_N
CCTS4_N
RRI4_M
GND
DDSR5_N
RRTS5_N
CCTS5_N
RRI5_N
GND
1
1
