1.1 Introduction
AIMB-501 is designed with the Intel H61 for industrial applications that require both
performance computing and enhanced power management capabilities. The mother-
board supports Intel Core i7-3770 3.4 GHz/Core i5-3550S 3.0 GHz/Core i7-2600 3.4
GHz/Core i5-2400 3.1 GHz/Core i3-2120 3.3 GHz/ Pentium G850 2.9 GHz/Celeron
G540 2.5 GHz processor up to 8 MB L3 cache and DDR3 1333/1600 up to 16 GB. It
has rich I/O connectivity of 10 serial ports, 10 USB 2.0, dual GbE LAN and 4 SATA II
ports.
1.2 Features
 Rich I/O connectivity: Dual GbE LAN via PCIe x 1 bus, 2 x PCI 32- bit/33 MHz
PCI slots, 10 USB 2.0 ports, 10 serial ports, 1 PCIe x 16, and 1 PCIe x 1.
 Standard Micro ATX form factor with industrial feature: The AIMB-501 is a
full featured Micro ATX motherboard with balanced expandability and perfor-
mance.
 Wide selection of storage devices: SATA HDD, customers benefit from the
flexibility of using the most suitable storage device for larger capacity.
 Optimized integrated graphic solution: With Intel® Flexible Display Interface,
it supports versatile display options and 32-bit 3D graphics engine.
1.3 Specifications
1.3.1 System
 CPU: Intel Core i7-3770 3.4 GHz/Core i5-3550S 3.0GHz/Core i7-2600 3.4GHz/
Core i5-2400 3.1GHz /Core i3-2120 3.3GHz/ Pentium G850 2.9GHz/Celeron
G540 2.5GHz processor
 BIOS: AMI EFI 64 Mbit SPI BIOS
 System chipset: Intel® H61
 SATA hard disk drive interface: Four on-board SATA connectors with data
transmission rate up to 300 MB
1.3.2 Memory
 RAM: Up to 16 GB in 2 slots 240-pin DIMM sockets. Supports dual-channel
DDR3 1333/1600 MHz SDRAM.
– Supports non-ECC unbuffered DIMMs and do not support any memory con-
figuration that mixes non-ECC with ECC unbuffered DIMMs.
Note! A 32-bit OS may not fully detected 16 GB of RAM when 16 GB is
installed.
