AIMB-501 User Manual 16
DUALPWR2- Jumper for on board USB
DUALPWR3- Jumper for rear side USB & PS/2 KBMS
2.4 VGA1/ DVI-D Connector (VGA1 + VGA2 + DVI1)
AIMB-501 includes VGA and DVI interfaces that can drive conventional VGA and DVI
displays. VGA is a standard 15-pin D-SUB connector commonly used for VGA. Pin
assignments for VGA and DVI connectors are detailed in Appendix B.
Note! When USB power is switched to +5V, it can't be connected with power
KVM.
