B.6 COM Port Connector (COM1/COM2)
B.7 COM Port Connector (COM3456/COM78910)
Table B.6: COM Port Connector (COM1/COM2)
COM1/COM2 COM Port Connector
Part Number 12G07120010T
Pin Pin Name
1 DDCD1#
2 DDSR1#
3 RRXD1
4 RRTS1#
5 TTXD1
6 CCTS1#
7 DDTR1#
8 COM1_RRI1
9 GND
