2.9 Front Panel Connectors (JFP1/JFP2/JFP3)
There are several headers for monitoring and controlling the AIMB-501.
JFP3 Front panel connector
Pin Pin Name
1 SIO_SUSLED
2NC
3GND
4 #KEYLOCK
5GND
JFP1+
JFP3
JFP2
