AIMB-501 User Manual 30
2.21 LPC Connector for Debug (LPC1)
3 SIO_SPIO2
4 SIO_SPIO3
5 SIO_SPIO4
6 SIO_SPIO5
7 SIO_SPIO6
8 SIO_SPIO7
9VCC_GPIO
10 GND
LPC1
