5 ASMB-785 User Manual
Chapter 1 Hardware Configuration
JSKTOCC1
To force power when no CPU installed, normal (1-2)/
debug (2-3)
Table 1.2: Connector list
Label Function
ATXPWR1 ATX 24 Pin main power connector (for system)
ATX12V1 Processor power connector (for CPU)
SATA0~6 SATA III (6 Gb/s)
USB7_8, USB9_10, USB11_12 USB 2.0 Port (Header)
USB13 USB 2.0 Port (USB Type A)
USB3_4 USB 3.0 Port (Header)
PCI_SLOT1, PCI_SLOT3,
PCI_SLOT5
PCI slot
PCIEX4_SLOT2, PCIEX4_SLOT7 PCIe x4 slot (Gen3 x4 link)
PCIEX16_SLOT4,
PCIEX16_SLOT6
PCIE x16 slots (one Gen3 x16 link for slot 6 or two Gen3
x8 link)
DIMMA0,DIMMA1,
DIMMB0,DIMMB1
DDR4 288-pin slot
CPUFAN0 CPU FAN connector
SYSFAN0,SYSFAN1,
SYSFAN2,SYSFAN3
System FAN connector
LAN1_USB1_2, LAN2_USB5_6
LAN1 / USB 3.0 port 1, 2 stack connector
LAN2 / USB 3.0 port 5, 6 stack connector
LAN3_4 LAN3 & LAN4 connector
VGA1_COM1 VGA+COM connector
DVI1_DVI2 DVI-D connector
KBMS1 External keyboard and mouse connector (6 pin)
SPI_CN1 SPI flash card pin header
LANLED1~2 LAN LED extension connector
SMBUS1 SM Bus From PCH
GPIO1 8-bit GPIO header
FPAUD1 Audio front panel header
COM2, COM3_4, COM5_6 Serial port: RS-232
LPC1
Low pin count connector for Advantech TPM LPC and
RS232/422/485 modules.
VOLT1 Voltage display
AUDIO1 Audio connector
BH2 For optional battery kit
EX_THR1 For thermometer kit
SGPIO1, SGPIO2 Serial General Purpose I/O
JFP1 Power Switch / Reset connector
JFP2 External speaker/HDD LED connector/SMBus connector
JFP3 Keyboard Lock and Power LED
SPDIF_OUT1 SPDIF audio output pin header
BMC1 BMC connector to support IPMI-1000 module
PMBUS1 PMBUS connector to communicate with power supply
Table 1.1: Jumper list
