Advantech ASMB-785 - Front Panel Connectors (JFP1;2;3)

23 ASMB-785 User Manual
Chapter 2 Connecting Peripherals
2.9 Front Panel Connectors (JFP1/2/3)
There are several external switches and LEDs to monitor and control the ASMB-785.
JFP1+JFP2
JFP3
3 6 9 12
25811
PWRSW RESET
HDDLED
SNMP
JFP1
&
25811
1 4 7 10
HDDLED
SM_BUS
SPEAKER
JPF2
&
PWRLED & KEYLOCK
1 2 3 4 5JFP3
