Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 CPU
 Supports one E3-1200 v5/v6 Series and 6th/7th Gen. Core i3, i5 & i7 CPU in an
LGA1151 socket.
 Max. TPD can support up to 91 W.
1.3.2 PCH
 System Chipset: Intel® C236
 SATA hard disk drive interface: Six on-board SATA III connectors support
Advanced Host Controller Interface (AHCI) technology, Intel Rapid Storage
Technology (IRST) for software RAID 1, 0, 10 and 5 support, and have data
transmission rates up to 600 MB/s.
1.3.3 Memory
 RAM: Up to 64 GB in four 288-pin DIMM sockets. Supports dual-channel DDR4
ECC/Non-ECC 1600/1866/2133/2400 unbuffered U-DIMM.
1.3.4 Input/Output
 PCIe slot (Gen3): 1 PCIe x16 expansion slot with x16 link or switchable to 2
PCIe x16 expansion slots with x8 link, or 2 PCIe x4 expansion slots with x4
links.
 PCI slot: 3 PCI slot, 32-bit, 33 or 66 MHz PCI 2.2 compliant, and clock could be
selected by jumper(JPCICLK1).
 Enhanced parallel port: Configured to LPT1 or disabled. Standard DB-25
female connector cable is a optional accessory. LPT1 supports EPP/SPP/ECP.
 Serial port: Six serial ports (1 in rear and 5 onboard), only supports RS-232.
 PS/2 Keyboard and mouse connector: To save rear I/O space, ASMB-785
reserves a 6-pin header on board (KBMS1) and via a cable kit to build two 6-pin
mini-DIN connectors for easy connection to PS/2 keyboard and mouse.
 USB port: Supports up to 6 USB 3.0 ports with transmission up to 5Gbps and 7
USB 2.0 ports with transmission rates up to 480 Mbps.
 LPC: One LPC connector supports Advantech TPM LPC modules and COM
232/485 modules. (Slot-2 & 3 can't be used when COM module is installed.)
 GPIO: ASMB-785 supports 8-bit GPIO from super I/O for general purpose con-
trol application.
1.3.5 Graphics
 Graphics processor: Integrated Intel HD Graphics.
 Display memory: 1 GB maximum shared memory with 2 GB and above system
memory installed
 DVI-D: Two DVI-D ports up to resolution 1920 x 1200 @ 60 Hz refresh rate
 D-Sub: Up to 1920 x 1200 resolution @ 60 Hz refresh rate
Note! 1. Due to the inherent limitations of PC architecture, the system may not
fully detect 64 GB RAM when 64 GB RAM is installed.
2. A 32-bit OS may not fully detect 4 GB of RAM when 4 GB is installed.

Advantech ASMB-785 Specifications

General

Brand	Advantech
Model	ASMB-785
Category	Motherboard
Language	English
