ASMB-785 Ordering Information
Initial Inspection
Before you begin installing your motherboard, please make sure that the following
materials have been shipped:
1 ASMB-785 Startup Manual
1 Driver CD (user’s manual is included)
2 Serial ATA HDD data cables (including 1 right angle cable)
2 Serial ATA HDD power cables
1 I/O port bracket
1 Warranty card
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately. We have carefully inspected the ASMB-785 mechanically and
electrically before shipment. It should be free of marks and scratches and in perfect
AIMB-R43PF-21A1E Advantech
AIMB-R43PF (2U
riser card)
1*PCIe x16 slot
AIMB-RP3P8-12A1E Advantech
AIMB-R43PF (2U
riser card)
2*PCIe x8 slot
ASMB-RF348-21A1E Advantech
ASMB-RF348
(2U riser card)
1*PCIe x4(slot 1) +
1*PCIe x8(slot3)
Slot6 need to be con-
figured as x8x8 link
via jumper "JPEG1"
and "JPEG2"
ASMB-RF3X8-21A1E Advantech
ASMB-RF3X8
(2U riser card)
1*PCIe x8(slot 1) +
2*PCI-X(slot2 & 3)
Slot6 need to be con-
figured as x8x8 link
via jumper "JPEG1"
and "JPEG2"
ASMB-RF388-21A1E Advantech
ASMB-RF388 (2U
riser card)
1*PCIe x8 +
2*PCIex4 slot
Slot6 need to be con-
figured as x8x4x4 via
jumper "JPEG1" and
"JPEG2"
Note! 1. Above list is subject to change. Please contact your sales or FAE for
peripheral list.
2. We strongly recommend to purchase all peripheral parts from Advan-
tech to avoid any compatibility issues.
3. Please refer to the table 1.8.1.7 for detail JPEG jumper setting.
Part Number Chipset Memory LAN Display IPMI
ASMB-785G4-00A1E C236
DDR4 288pin ECC/Non-
ECC unbuffered DIMM
4
2*DVI +
1*VGA
Optional
Module
(IPMI-1000-
00A2E)
ASMB-785G2-00A1E C236
DDR4 288pin ECC/Non-
ECC unbuffered DIMM
2
2*DVI +
1*VGA
Optional
Module
(IPMI-1000-
00A2E)
To Next Page
