Advantech EPC-P30X6 Series - default chapter; Table of Contents

xiii EPC-P30X6 User Manual/ 用户手册
Contents/目录/目錄
Chapter 1 General Information
概述
產品資訊 .......................... 1
1.1 Specifications/ 产品规格 / 產品規格 ................................2
Table 1.1: General Features of EPC-T2000 series/
EPC-T2000 系列一般特性 .......................2
1.2 Environmental Specification/ 环境规格 / 環境規格 ...................3
Table 1.2: Environmental Specification/ 环境规格 / 環境規格 .3
1.3 Power Supply Options/ 电源选项 / 電源選項 ........................3
Table 1.3: Power Supply Options/ 电源选项 / 電源選項 ......3
1.4 Dimensions/ 产品尺寸 / 產品尺寸..................................4
Figure 1.1 Dimensions/ 产品尺寸 / 產品尺寸.................4
1.5 IO / 串口.......................................................5
1.6 Optional Riser Card/ 转板选择 / 轉板選擇 ..........................6
1.6.1 EPC-RF484-13A1E....................................................................... 6
1.6.2 EPC-RF48P-22A1E ...................................................................... 7
1.6.3 EPC-RF2F4-11A1E ...................................................................... 8
1.6.4 EPC-RF4F1-13A1E ...................................................................... 9
Chapter 2 Connecting
内部连接
內部連接 ......................... 11
2.1 Top Layer Overview................................................................................ 12
2.2 Bottom Layer Overview........................................................................... 13
2.3 Connector and Header List ..................................................................... 14
2.3.1 DCIN power connector (DCIN1) ................................................. 15
2.3.2 SPI BIOS flash socket (SPI1) ..................................................... 15
2.3.3 SPI Pin Header (SPI_CN1)......................................................... 16
2.3.4 CPU FAN connector (CPUFAN1) ............................................... 16
2.3.5 PWRBTN#/ RESET#/HDD LED Header (JFP1)......................... 17
2.3.6 DDR4 SODIMM socket A1 (DIMMA1) ........................................ 17
2.3.7 DDR4 SODIMM socket B1 (DIMMB1) ........................................ 17
2.3.8 Gold Finger 1 (GF1).................................................................... 18
2.3.9 Gold Finger 2 (GF2).................................................................... 19
2.3.10 COM5 / 6 connector (COM56).................................................... 20
2.3.11 COM3 / 4 connector (COM34).................................................... 20
2.3.12 COM1 / 2 connector (COM12).................................................... 21
2.3.13 RJ45 + USB3.0 stack connector (LAN3_USB56)....................... 21
2.3.14 RJ45 + USB3.0 stack connector (LAN2_USB34)....................... 22
2.3.15 RJ45 + USB3.0 stack connector (LAN1_USB12)....................... 23
2.3.16 HDMI1 stack connector (HDMI1)................................................ 24
2.3.17 VGA1 stack connector (VGA1) ................................................... 24
2.3.18 PWRBTN(PWRBTN1) ................................................................ 25
2.3.19 UART1/2, STAT LED (LED1)...................................................... 25
2.3.20 SATA Power Connector (SATA PWR3/PWR2/PWR1)............... 25
2.3.21 System Fan connector (SYSFAN1) ............................................ 26
2.3.22 SIM Card 1 (SIM1/SIM2)............................................................. 26
2.3.23 M.2 B Key connector(M2B1)....................................................... 27
2.3.24 M.2 E Key connector (M2E1)...................................................... 28
