1.6.4 EPC-RF4F1-13A1E
EPC-P3066/P3076 series
Configuration 1:
EPC-P3086 series
*. Custom BIOS is required
*. Project Base is required
1 PCIe x 16 5 SATA
2 PCIe x 1 6 SATA Power
3 PCIe x 1 7 12V output
4 PCIe x 1 8 FAN Power Connector
1 PCIe x 16 5 SATA
2 PCIe x 1 6 SATA Power
3 PCIe x 1 7 12V output
4 PCIe x 1 8 FAN Power Connector
1
2
3
4
5
6
7
8
