EPC-P30X6 User Manual/ 用户手册 8
1.6.3 EPC-RF2F4-11A1E
EPC-P3066/P3076 series
EPC-P3086 series
1 PCIe x 16 5 12V output
2 PCIe x 4 6 FAN Power Connector
3SATA 7
4 SATA Power 8
1 PCIe x 16 5 12V output
2 PCIe x 4 6 FAN Power Connector
3SATA 7
4 SATA Power 8
1
2
3
4
5
6
