Advantech EPC-P30X6 Series - Watchdog Timer Output and OBS Beep (JIR1+JOBS1)

EPC-P30X6 User Manual/ 用户手册 38
2.4.2 Watchdog timer output and OBS beep (JIR1+JOBS1)
Clear CMOS Data
Function Jumper Setting
Watchdog Timer Output(2-3) (Default)
OBS BEEP(4-5) (Default)
(4 and 6)+(8 and 9)
Watchdog Timer Disable (1-2)
OBS BEEP(4-5) (Default)
(1 and 2)+(8 and 9)
