Chapter 2 Connecting 内部连接 內部連接
2.3.5 PWRBTN#/ RESET#/HDD LED Header (JFP1)
2.3.6 DDR4 SODIMM socket A1 (DIMMA1)
Please see JEDEC STANDARD.
2.3.7 DDR4 SODIMM socket B1 (DIMMB1)
Please see JEDEC STANDARD.
Pin Signal Pin Signal
1 FP_PANSWIN# 2 GND
3 FP_SYS_RESET# 4 GND
5 FP_SYS_RESET# 6 +V3.3
