EPC-P30X6 User Manual/ 用户手册 14
2.3 Connector and Header List
Description Part Reference
1 DCIN power connector DCIN1
2 CPU SCOKET LGA 1151 H4 CPU1
3 SPI BIOS Flash Socket SPI1
4 SPI Pin Header SPI_CN1
5 CPU FAN connector CPUFAN1
6 PWRBTN#/ RESET#/HDD LED Header JFP1
7 DDR4 SODIMM socket A1 DIMMA1
8 DDR4 SODIMM socket B1 DIMMB1
9 Gold Finger 1 GF1
10 PCH Heatsink HS1
11 Gold Finger 2 GF2
12 COM5 / 6 connector COM56
13 COM3 / 4 connector COM34
14 COM1 / 2 connector COM12
15 RJ45 + USB3.0 stack connector LAN3_USB56
16 RJ45 + USB3.0 stack connector LAN2_USB34
17 RJ45 + USB3.0 stack connector LAN1_USB12
18 HDMI1 stack connector HDMI1
19 VGA1 stack connector VGA1
20 PWRBTN PWRBTN1
21 UART1/2, STAT LED LED1
22 SATA Power Connector SATA_PWR3
23 SATA Power Connector SATA_PWR2
24 SATA Power Connector SATA_PWR1
25 Buzzer SP1
26 System Fan connector SYSFAN1
27 SIM Card 1 SIM1
28 SIM Card 2 SIM2
29 M.2 B Key connector M2B1
30 M.2 E Key connector M2E1
31 AT/ATX Mode selection PSON1
32 USB Power selection for USB78/ USB910 JUSBPWR2
33 Universal Serial Bus Port 9 / 14 USB910
34 Case Open connector JCASE1
35 Power LED pin header JFP2
36 I2C pin header JFP3
37 Watchdog timer output and OBS beep JWDT1+JOBS1
38 Universal Serial Bus 3.1 Port 7 / 8 USB78
39 CMOS battery connector BAT1
40 Serial ATA interface connector SATA1
41 Serial ATA interface connector SATA3
42 Serial ATA interface connector SATA2
43 COMS Mode selection JCMOS1
44 8-bits General Purpose I/O pin header GPIO1
45 8-bits General Purpose I/O pin header GPIO2
46 Low pin count interface connector LPC1
