7 EPC-P30X6 User Manual/ 用户手册
Chapter 1 General Information 概述 產品資訊
1.6.2 EPC-RF48P-22A1E
EPC-P3066/P3076 series
Configuration 1:
Configuration 2:
EPC-P3086 series
1PCIe x 8 5 SATA
2 PCIe x 8 6 SATA Power
3 PCI 7 12V output
4 PCI 8 FAN Power Connector
1 PCIe x 16 5 SATA
2 N/A 6 SATA Power
3 PCI 7 12V output
4 PCI 8 FAN Power Connector
1 PCIe x 16 5 SATA
2 N/A 6 SATA Power
3 PCI 7 12V output
4 PCI 8 FAN Power Connector
1
2
3
4
5
6
7
8
