Advantech PCA-6186 - Keyboard and Mouse Connnector (CN11); External Keyboard Connector (CN12)

115 Appendix B
B.8 Keyboard and Mouse Connnector (CN11)
Table B.8: Keyboard and mouse connector (CN11)
Pin Signal
1 KB DATA
2MS DATA
3GND
4VCC
5 KB CLOCK
6 MS CLOCK
B.9 External Keyboard Connector (CN12)
Table B.9: External keyboard connector (CN12)
Pin Signal
1CLK
2DATA
3NC
4GND
5VCC
5
3
12
4
6
