PCA-6186 User’s Manual 4
9. More:
• Power On by Alarm: Powers up your computer at a certain time.
• Virus warning: During and after system boot-up, any attempt to write to
the boot sector or partition table of the hard disk drive will halt the sys-
tem. In this case, a warning message will be displayed. You can then
run your anti-virus program to locate the problem
1.3 Specifications
1.3.1 System
• CPU: PCA-6186 supports Intel Pentium® 4/ Celeron™ up to 2.4GHz
and the above, FSB 400/533 MHz.
• Firmware hub: Provides security enhancements on computer plat-
forms by supporting Random Number Generator (RNG)
• BIOS: Award Flash BIOS (4Mb Flash Memory)
• System Chipset: Intel® 845GV chipset
• PCI enhanced IDE hard disk drive interface: Supports up to four
IDE (AT-bus) large hard disk drives or other enhanced IDE devices.
Supports PIO mode 4 (16.67 MB/s data transfer rate) and Ultra ATA
100/66/33 (100/66/33 MB/s data transfer rate). BIOS enabled/disabled
• Floppy disk drive interface: Supports up to two floppy disk drives,
5¼" (360 KB and 1.2 MB) and/or 3½" (720 KB, 1.44 MB). BIOS
enabled/disabled
1.3.2 Memory
• RAM: Up to 2GB in two 184-pin DIMM sockets. Supports DDR200/
266/333 SDRAM.
• ECC: not supported
1.3.3 Input/Output
• Bus interface: PCI/ISA bus, PICMG compliant
• Enhanced parallel port: Configurable to LPT1, LPT2, LPT3, or dis-
abled. Standard DB-25 female connector provided. Supports EPP/SPP/
ECP
• Serial ports: Two RS-232 ports with 16C550 UARTs (or compatible)
with 16-byte FIFO buffer. Supports speeds up to 115.2 Kbps. Ports can
be individually configured to COM1, COM2 or disabled
• Keyboard and PS/2 mouse connector: One 6-pin mini-DIN connector
is located on the mounting bracket for easy connection to a keyboard or
