125 Appendix B
Table B.28: PCI bus map (for VG/G2 version*)
Function Signals:
Device ID INT# pin GNT# pin
Onboard LAN1 AD21 INT G GNT E
Onboard LAN2 AD20 INT H GNT A
Bridge AD22 GNT F
PCI slot 1 AD31 INT B, C, D, A GNT A
PCI slot 2 AD30 INT C, D, A, B GNT B
PCI slot 3 AD29 INT D, A, B, C GNT C
PCI slot 4 AD28 INT A, B, C, D GNT D
* The "Onboard LAN2" is not available for VG.
