Advantech PCI Series User Manual

PCI Communication User Manual 4
 Power Consumption
 Operating Temperature: -10~60°C (14~144°F)
 Operating Humidity: 5~95% relative humidity, non-condensing
 Storage Temperature: -25~85°C (-13~185°F)
 Current Value: 20 mA (standard)
 Mode:
RS-232/422: Asynchronous, full duplex
RS-485: Asynchronous, half duplex
 Baud Rate: 50~921.6 Kbps
 Transmission Distance:
RS-232 < 15 m
RS-422/485 < 1000 m
Table 1.2: Power Consumption
Model Name Typical Maximum
PCI-1602B 260 mA @ +3.3 V 330 mA @ +3.3 V
PCI-1602C 260 mA @ +3.3 V 450 mA @ +3.3 V
PCI-1602UP 260 mA @ +3.3 V 420 mA @ +3.3 V
PCI-1604C 260 mA @ +3.3 V 450 mA @ +3.3 V
PCI-1610B 260 mA @ +3.3 V 530 mA @ +3.3 V
PCI-1610C 260 mA @ +3.3 V 680 mA @ +3.3 V
PCI-1612B 260 mA @ +3.3 V 530 mA @ +3.3 V
PCI-1612C 260 mA @ +3.3 V 680 mA @ +3.3 V
PCI-1620A 260 mA @ +3.3 V 880 mA @ +3.3 V
PCI-1620B 260 mA @ +3.3 V 880 mA @ +3.3 V
PCI-1622B 260 mA @ +3.3 V 880 mA @ +3.3 V
PCI-1622C 260 mA @ +3.3 V 1250 mA @ +3.3 V
Note! PCI-1602UP uses PI7C8952 as the communication controller.
