Advantech PCI Series User Manual

5 PCI Communication User Manual
Chapter 1 Introduction
1.3.2 Ordering Information
1.3.2.1 Accessories
 OPT4A-AE: 30-cm male DB-37 to 4 x male DB9 cables
 OPT8C-AE: 1-m male DB-62 to 8 x male DB-25 cables
 OPT8H-AE: 1-m male DB-62 to 8 x male DB-9 cables
 OPT8J-AE: 1-m male DB-78 to 8 x male DB-9 cables
 OPT8HP: 1-m double shield DB-62 to 8 x DB-9 cables
 OPT8AP-AE: 8-port RS-232(DCE) connection box w/(F) DB25 connector
Table 1.3: Model List
Product Description
PCI-1602B 2-port RS-232/422/485 PCI comm. card w/surge protection
PCI-1602C 2-port RS-232/422/485 PCI comm. card w/surge and isolation protection
PCI-1602UP 2-port RS-232/422/485 low-profile PCI comm. Card w/surge and isolation pro-
tection
PCI-1604C 2-port RS-232 PCI comm. card w/surge and isolation protection
PCI-1610B 4-port RS-232 PCI comm. card w/surge protection
PCI-1610C 4-port RS-232 PCI comm. card w/surge and isolation protection
PCI-1612B 4-port RS-232/422/485 PCI comm. card w/surge protection
PCI-1612C 4-port RS-232/422/485 PCI comm. card w/surge and isolation protection
PCI-1620A 8-port RS-232 PCI comm. card
PCI-1620B 8-port RS-232 PCI comm. Card w/surge protection
PCI-1622B 8-port RS-232/422/485 PCI comm. card w/surge protection
PCI-1622C 8-port RS-232/422/485 PCI comm. card w/surge and isolation protection
Table 1.4: PCI Communication Card Selection Guide
Model Ports Comm. Interface Support
Protection
Surge Isolation
PCI-1602
B
2
RS-232/422/485 1000 V
C RS-232/422/485 1000 V
3000 V
DC
UP RS-232/422/485 1000V
3000 V
DC
PCI-1604 C RS-232 1000 V
3000 V
DC
PCI-1610
B
4
RS-232 1000 V
C RS-232 1000 V
3000 V
DC
PCI-1612
B RS-232/422/485 1000 V
C RS-232/422/485 1000 V
3000 V
DC
PCI-1620
A
8
RS-232
B RS-232 1000 V
PCI-1622
B RS-232/422/485 1000 V
C RS-232/422/485 1000 V
3000 V
DC
