Advantech PCI Series User Manual

27 PCI Communication User Manual
Chapter 4 ICOM Tools
4.3.2 Tool Bar
The toolbar icons are described as follows:
Port Select: Selects the port(s) you want to perform testing on
Port Setup: Sets up configuration of the port you have selected
Port Close: Closes the port you have selected
Port Run: Runs the port test on the port you have selected
Port Stop: Stops the port test on the port you have selected
All Ports Setup: Sets up the configuration of all ports not running tests
All Ports Run: Runs the test on all ports
All Ports Stop: Stops the test on all ports
Clear Message: Clears messages in the Message Logo panel and the Rx
length information in the Performance Listing panel
