Advantech PCI Series User Manual

3 PCI Communication User Manual
Chapter 1 Introduction
1.3 Specifications
1.3.1 Bus Interface
The following table shows the bus specifications of the comm. cards.
 IRQ: All ports use the same IRQ assigned by PCI Plug-and-Play
 Data bits: 5, 6, 7, 8
 Stop bits: 1, 1.5, 2
 Parity: None, Even, Odd, Mark, and Space
 Speed (bps):
 Data Signals:
 Dimensions
 Bus Interface  Models
PCI Bus Specifications 2.2
PCI-1602B, PCI-1602C, PCI-1602UP, PCI-1604C, PCI-
1610B, PCI-1610C, PCI-1612B, PCI-1612C, PCI-1620A,
PCI-1620B, PCI-1622B, PCI-1622C
Model Criteria Speed (bps)
PCI Series
A level 50~921.6 kbps
B level 50~921.6 kbps
Table 1.1: Transmission Modes
BUS Interface Model Name Ports Communication Interface
RS-232 RS-422 RS-485
PCI PCI-1602B 2 V V V
PCI-1602C 2 V V V
PCI-1602UP 2 V V V
PCI-1604B 2 V
PCI-1604C 2 V
PCI-1610B 4 V
PCI-1612B 4 V V V
PCI-1612C 4 V V V
PCI-1610C 4 V
PCI-1620A 8 V
PCI-1620B 8 V
PCI-1622B 8 V V V
PCI-1622C 8 V V V
1. RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI
2. RS-422: Tx+, Tx-, Rx+, Rx-, CTS+, CTS-, RTS+, RTS-
3. RS-485: Data+, Data-
Size Model
119.91 x 106.67 mm
(4.72” x 4.2")
PCI-1602B, PCI-1602C, PCI-1604C
174.65 x 106.67 mm
(6.88” x 4.2")
PCI-1610B, PCI-1610C, PCI-1612B, PCI-1612C, PCI-1620A,
PCI-1620B, PCI-1622B, PCI-1622C
119.91 x 64.41 mm
(4.7" x 2.5")
(low-profile MD1)
PCI-1602UP
