15 PCI Communication User Manual

Chapter 2 Hardware Configuration

Note: On: 0, Off: 1

2.3.3.3 Tx Enable Mode Selection (SW2)

Tx Enable Mode is set by two, four, or eight position DIP switches (one for each port).

If a switch is set to “On,” the driver of the corresponding port will always be enabled,

and the COM port will change to RS-422 master mode, which means that the Tx out-

put is always enabled. If a switch is set to “OFF,” the driver will be in Auto Direction

Control Mode. You must select a mode before beginning any RS-422 applications.

(PCI-1620A/PCI-1620B/PCI-1622B are SW1)

11 OFF ON OFF OFF

12 OFF OFF ON ON

13 OFF OFF ON OFF

14 OFF OFF OFF ON

15 OFF OFF OFF OFF

Table 2.2: Board ID Setting

Table 2.3: Tx Enable Mode Selection

Mode Switch Position Description

RS-422_Master ON Tx always enabled

RS-422_Slave/RS-485 OFF Auto direction control enabled

Note! Do not set termination resistors in RS232 mode.
