Advantech PCI Series User Manual

51 PCI Communication User Manual
Appendix A Scale of Connectors
Figure A.4 DB62 Female
Figure A.5 DB78 Female
POSITIONABCDEF
62 Pin 55.42 63.50 69.32 1.98 8.36 12.55
POSITION A B C D1 D2 E F
78 Pin 67.16±0.38 61.11±0.25 52.40±0.20 2.41 2.08 10.72±0.25 14.1±0.25
