Advantech WISE-4210 Series User Manual

WISE-4210 Series User Manual 14
2.1 General Specification
2.1.1 Wireless Interface
 IEEE Standard
– IEEE 802.15.4g
 Operating Frequency
– NA923: 923MHz (920.8~924.4),BW:400KHz
– EU868: 868MHz (865.2~868.8),BW:400KHz
 Data Rate:
– WISE-4210-AP: 625 bps/ 2.5K bps / 5K bps / 50K bps
– WISE-4210 Node: 625 bps, 50K bps
 Outdoor Range
– 625bps: 5 km (Line of sight)
– 50kbps: 2 km (Line of sight)
 Antenna Gain
– 902~928MHz: 1.48 dBi
– 863~870MHz: 2.02 dBi
 Transmit Power (CE): 14dBm±1dBm
 Receiver Sensitivity:
– 115 dBm @ 625bps (Long-Rang Mode)
– 100 dBm @50Kbps
 Topology: Star
 Network Capacity: Up to 64 end nodes
 Channel List:
EU868
BW: 400K Hz
(Frequency: MHz)
NA915
BW: 400K Hz
(Frequency: MHz)
UN433
BW: 300K Hz
(Frequency: MHz)
Chanel 1 865.2 Chanel 1 920.8 Chanel 1 433.2
Chanel 2 865.6 Chanel 2 921.2 Chanel 2 433.5
Chanel 3 866.0 Chanel 3 921.6 Chanel 3 433.8
Chanel 4 866.4 Chanel 4 922.0 Chanel 4 434.1
Chanel 5 868.8 Chanel 5 922.4 Chanel 5 434.4
Chanel 6 867.2 Chanel 6 922.8
Chanel 7 867.6 Chanel 7 923.2
Chanel 8 868.0 Chanel 8 923.6
Chanel 9 868.4 Chanel 9 924.0
Chanel 10 868.8 Chanel 10 924.4
Note! The transmitting distance is subject to the environment of application
site. Please perform site survey to determine the set up range of the
wireless network.
