2. Prepare the UAV
2.1 Components
12
13
1
2
3
6
4
7
5
8
9
10
11

Fig.8
1. Blade
2. Motor
3. ReararmLED
4. Battery
5. Batteryfastener
6. Opticalowmodule
7. Landinggear
8. Retractbutton
9. Airbag
10. Three-axisgimbalcamera
11. FrontarmLED
12. BatteryLED
13. Powerbutton

2.2 Flight Control System
TheAEEightcontrolsystemofCondorisstableandeasytooperate.Itsupportsthebasicliftingand
pitchingactionsandthefail-safe,lowpoweralarmandlow-powerlandingfunctions.
ModulesofFlightControlSystemDescription
ModulesofFlightControlSystem Description
Mastercontroller
Acoremodule,controllingallothermodulesinan
integratedmanner
GPSandcompass UAVpositioningandnavigation
LED
Indicatesightcontrolsystemstatusandnavigate
theUAVinnightights
