V. Onboard Camera Upgrade
(1) Visitourocialwebsitewww.aee.comtodownloadthelatestCondoronboardcameraupgradepackage.
(2) Decompressthedownloadedupgradepackageintotwoles:rmware.binandautoexec.ash.Copythese
twolestotheformattedTFcard.
(3) InserttheTFcardintothecardslotoftheonboardcamera,powerontheUAVwiththepropellers
removed,starttheupgradingprocess,andthenwaitabout2minuntiltheupgradingprocessis
completed.FormattheTFcard.
VI. Appendix
1. Common LEDs
NormalStatus
ThefrontarmLEDandgreenreararmLEDremainon InGPSmode
ThefrontarmLEDandyellowreararmLEDremainon Innormalmode
ThefrontarmLEDandbluereararmLEDremainon Invisualpositioningmode
AlarmsandErrors
ThefrontandreararmLEDsashslowly Level-1lowpoweralarm
ThefrontandreararmLEDsashquickly Level-2lowpoweralarm
ThefrontarmLEDremainsonandthereararmLED
ashesredandyellowalternately
Compasserror
Thefrontandrear(red)armLEDsashalternately. Smartbatteryerror
TheaboveLEDsarecommonightLEDs.RefertothesectionFlightLEDsformoreinformation.
2. Specications
UAV
Battery 6,800mAhLiPo
Weight 1.68Kg(1.8KgforCondorElite)
Hoveringaccuracy Horizontal:±1.5m
Vertical:±0.5m
Maximuminclinationangle 20°
Maximumascending/
descendingspeed
Ascend:5m/s
Descend:2.5m/s
Maximumightspeed 16m/s(notrecommended)
Shaftdistance 400mm
Flighttime ≤20min
