4.7 Remote Control Operations
Joystickinneutral:theremotecontroljoystickisintheneutralposition.
Joystickshift:theextentoftheremotecontroljoystickshiftfromtheneutralposition.
RemoteControl
UAV(“
”indicatestheheading)
Operations
Ascend
Descend
Ascend
Descend
ControltheUAV’saltitude:
push/pulltheleftjoystickup/
downtoenabletheUAVto
ascend/descend.Incaseof
joystickinneutral,theUAV
willnotmoveupordown.To
takeo,pushtheleftjoystick
upslowly(quickpushingmay
causetheUAVtoascend
rapidlysuddenly)untilabove
theneutralposition.
Tu
rn Lef
tTurn Right
Turn Left
Turn Right
ControltheUAV’sheading:
pushtheleftjoystickleft/
righttoenabletheUAVto
turncounterclockwise/
clockwise.Incaseofjoystick
inneutral,theUAVwillnot
turn.Agreaterjoystickshift
willleadtoahigherturning
angularvelocity.
Fly Forward
Fly Backward
Fly Forwar
dF
ly Backward
Push/pulltherightjoystick
up/downtoenabletheUAV
topitchforward/backward
andyforward/backward.
Incaseofjoystickinneutral,
theUAVwillkeephorizontal
inthefront-backdirection.A
greaterjoystickshiftwilllead
toalargerpitchingangleand
higherightspeed.
Fly LeftFly Right
Fly Left Fly Right
Pushtherightjoystickleft/
righttoenabletheUAVto
pitchleft/rightandyleft/
right.Incaseofjoystickin
neutral,theUAVwillkeep
horizontalintheleft-right
direction.Agreaterjoystick
shiftwillleadtoalarger
pitchingangleandhigher
ightspeed.
