3. Prepare the Propellers and Propeller Guard Rings
Condoruses10.5inchpropellers,whosecapsaremarkedorunmarkedwith“P”.Propellerisaconsumable.
Purchasenewpropellerswhennecessary.
3.1 Introduction for Propellers
Propeller With“P”-unmarkedCap(1045) With“P”-markedCap(1045P)
Sketch


Installationposition
Installontothemotorshaftsof
thearmsunmarkedwith“P”
Installontothemotorshaftsof
thearmsmarkedwith“P”
Directionmarks
Tighten:installthepropellerontothemotorinthisdirection.
3.2 Install the Propellers
AsshowninFig.13,preparetwopropellerswith“P”-markedcapandtwopropellerswith“P”-unmarkedcap
andinstallthemrespectivelyontothemotorshaftsofthearmsmarkedwith“P”andthemotorshaftsofthe
armsunmarkedwith“P”.Tightenthepropellersinthetightenmarkdirection.

Fig.13
(1) Tightentheself-propelledpropellersratherthanuseanyscrewglue..
(2) Makesureallpropellersareinstalledintheirplaces.ImproperinstallationmaycausetheUAVto
workimproperly.Toprotectthethinbladesagainstscratches,pleaseweargloveswhileinstallingthe
propellers.
3.3 Remove the Propellers

:UHQFK
7XUQLQJ'LUHFWLRQ
Fig.14
Toremovethepropeller,holdthemotorwiththe
wrenchorbyyourhandandturnthepropellerin
thedirectionoppositetothemark.
