21
5
ToggleswitchB
(ightmode)
Threepositions:
PositionP:positionmode,supportspothoverwithGPSorVisual
PositionM:normalmode,supportattitudestabilityaugmentation,noGPSor
Visual;
PositionN:neutralmode.
6 Homepointlock Pressandholdittoenable/disablethehomepointlockfunction
7 Recordkey Pressittostart/stoprecordingthevideo
8 JoystickA 1two-wayjoystick,supportyawingandthrottling
9 JoystickB 1two-wayjoystick,supportpitchingandrolling
10 Phoneholder Placeyourmobiledevice
11 Customkey
Triggertheremotecontrolbasecalibrationorremotecontrollanguage
selection
12 Hookkey
Pressittoopenthehookandpressitagaintoclosethehook.
Note:thehookisanoptionalaccessory.
13 Repeaterfastener
14 Powerbutton Pressitonceandthenlongpressitfor3stopoweron/otheUAV
15 Repeaterfastener
16 Antenna
Signaltransmitting/receivingantenna:
(1)2.4G(WiFi)HDimagetransmissionantenna
(2)2.4G(WiFi)datatransmissionantenna
17 LEDscreen
18 Lanyardhole 1lanyardhole,hangtheremotecontrol
19 Takeo/landkey Pressandholdittotakeoorland
20 Followmeswitch
PushittopositionON:enabletherepeaterfollowmefunction.
PushittopositionOFF:disabletherepeaterfollowmeusefunction.
21 Red/green/blueLED SameastheremotecontrolbatteryLED
22 Homekey Longpressittoreturnhome.Longpressitagaintocancelreturning.
23 Chargingport Chargetheremotecontrol
24 MicroUSBport USBrmwareupgrade
25 Yawleft
26 Ascend
27 Yawright
28 Descend
29
Flyleft/right/
forward/backward
30 Powerbutton Shortpressonceandlongpress3stoturnon/otheremotecontrol
31 Phoneholderswitch Pressandholdittoopen/closethephoneholder
