Set the picture format (4:3PS, 4:3LB, 16:9)
Since the device supports dierent picture formats (aspect ratios), it may happen that the displayed picture does
not ll the whole screen or the edges of the screen are cut o. In such cases, you must set the correct picture
format (aspect ratio):
1. Whilst the disc is playing or after you have stopped play by pressing the STOP button, press the SETUP button
on the remote to open the Setup menu.
2. The rst main menu GENERAL SETUP PAGE appears. If required select the rst icon in the top menu bar and
press the PLAY/ENTER button, to display the menu items.
3. Using the Navigation button ▼ select the menu item TV DISPLAY.
4. Then press the Navigation button ►, to display the available picture formats.
5. Using the Navigation button ▼ or ▲ select the required picture format. The following options are available:
• 4:3PANSCAN:SelectthisOption,tosetthepicturesothatitllsthewholescreen.PAN&SCANisaprocess
which will try to display part of a wide screen picture on a standard 4:3 television screen. Since the picture
can never be completely shown however, only the relevant section of the screen, for example, the actor who
is speaking is shown on the screen.
• 4:3LETTERBOX:SelectthisOption,tosetthepicturesothatitllsthewholescreen.Thepictureproportions
are retained and the picture is shrunk until the width of the picture ts a standard 4:3 television screen.
When the wide screen is displayed, a black strip appears on the left and right hand edge of the screen.
• 16:9WIDE:Selectthisoptionifyouhaveconnectedthedevicetoawidescreentelevision(WideScreen).If
you select this option for a normal television, the picture is distorted due to the vertical compression.
6. Then press the PLAY/ENTER button to conrm the selection.
7. Press the SETUP button again to close the Setup menu.
Notes:
• ThepictureformatdependsontherespectiveDVDdisc.Somediscscannotbeplayedinthedefaultpicture
format.
• Ifyouplayadiscwhichhasbeenrecordedin4:3format,onawidescreentelevision(16:9),ablackstripap-
pears on the left and right hand edge of the screen.
• Thepictureformatshouldbeadjustedtomatchthatoftheconnectedtelevision.
Connection to Audio devices
All Audio connections at a glance
The DVD device has analogue as well as digital inputs and outputs (ports/jacks) to connect audio devices.
The digital Audio System consists of a coaxial output COAXIAL and the optical output OPTICAL.
The analogue Audio System consists of the right and left Audio output FL and FR AUDIO OUTPUT, white and red
jacks) as well as the left and right jacks for the supplied speakers L and R SPEAKERS.
