6. L/R SPEAKERS (RCA jacks for the speakers): Use the jacks to connect the supplied right (R) and left (L) speakers
to the device.
7. OPTICAL (Optical Output): Use the optical output to connect an audio digital amplier (an external audio
device) to the DVD system MC 4434 DVD/USB/CR.
8. COAXIAL: Use the digital coaxial output to connect an audio digital amplier (an external audio device) to the
DVD system MC 4434 DVD/USB/CR.
9. Mains connection: To supply the device with power, the mains plug on the end of the mains cable should be
securely and fully plugged into the AC plug socket.
Connections to other devices – General notes
• Followtheconnectiondiagramsbelow,whichshowhowaudioandvideoexternaldevicesshouldbeproperly
connected to the DVD machine.
• Pleasereadandfollowcarefullytheusermanualsfordevices,whichneedtobeconnectedtotheDVDsystem.
• Beforeconnectingthedevicestoeachother,switchoanddisconnectfromthemains.
• Theports(AudioandVideoOutputs)arelocatedonthebackofthemachine.
• IfyouconnectexternalaudioandvideodevicestotheDVDsystem,payattentiontothecolourcodingofthe
audio and video cables as well as the corresponding jacks (input and output). The colour of the audio and video
jacks should match the colour of the input and outputs (jacks).
• Interference-freeoperationcanonlybeguaranteedwithaudio/videocablesofupto1.5metres.
• UndernocircumstancesshouldyouusethedigitalcoaxialoutputCOAXIALortheopticaloutputOPTICALat
the same time with analogue audio outputs.
• Donotblocktheventilationslotsofconnecteddevicesandcheckwhetheraircancirculatefreelyaroundthe
device.
• Donotbraidtheaudioandvideoconnectorcableswithothercablesorwires,especiallywithspeakerormains
cables. This may cause picture and sound interference.
• AfterallexternaldeviceshavebeenconnectedsecurelyandsafetytotheDVDmachine,plugallmainsplugs
from all devices into the mains sockets and switch on the DVD machine MC 4434 DVD/USB/CR as well as the
connected devices.
• Atleast3secondsshouldpassbetweenswitchingthemachineonando.
Video-Outputs: Connections to a television
All Video ports at a glance
The DVD system has four dierent video outputs, which can be used selectively to connect a television to the
system:
