AERMEC AN R407C - AN 100-150-200 Series Dimensions

40
750 1.750
1.345
57
100
300
57
Out
In
100 160
AN 100 - 150 - 200 (°) H
AN 100 - 150 - 200 A HA
750 1.750
1.345
340
466400
420
360
Out
In
Attacchi idraulici maschio ø 1”
Water connection male ø 1”
Microchiller
Microchiller
Attacchi idraulici femmina ø 1”½
Water connection female ø 1” ½
Attacchi idraulici femmina ø 1”¼
Water connection female ø 1” ¼
20
20 20
M8
30
20 20
8
M8
40
30 20
9
VT8 VT9
Microchiller
Microchiller
750
235
1.750
1.345
180
165
AN 100 - 150 - 200C
Microchiller
Microchiller
A
9 x 77
F
C
B
E
Mod.
AB C E FVT
100 °/H 707 750 1.670 605 430 8
100 A/HA 707 750 1.670 645 400 9
100 C 707 750 1.670 605 430 8
150 °/H 707 750 1.670 580 430 8
150 A 707 750 1.670 630 400 9
150 HA 707 750 1.670 680 400 9
150 C 707 750 1.670 580 430 8
200 °/H 707 750 1.670 580 430 8
200 A 707 750 1.670 630 400 9
200 HA 707 750 1.670 680 400 9
200 C 707 750 1.670 580 430 8
Linea
del gas ø55
Gas line ø55
Linea del
liquido ø38
Liquid line ø38
