DATI DIMENSIONALI • DIMENSIONS
AN 020 - 025 (°) - H
Out
In
352 900
850
140
250515,5
50
155
200
Mod.
AB C D E FVT
020 °/H 334 352 650 900 280 140 7
025 °/H 334 352 650 900 295 145 7
020 A/HA 408 435 660 1.120 385 185 7
025 A/HA 408 435 660 1.120 350 180 7
020 C 334 352 650 900 280 140 7
025 C 334 352 650 900 295 145 7
Attacchi idraulici maschio ø 1”
Water connection male ø 1”
Microchiller
Microchiller
Fori per collegamenti elettrici
Holes for electrical connections
F
A
Ø 10
C
E
B
D
352 900
850
50
155
200
325
70 140
Linea del
liquido ø47
Liquid line ø47
Linea
del gas ø47
Gas line ø47
AN 020 - 025 C
1.120
864
Out
In
431,5
75
280
230
108
80
435
AN 020 - 025 A - HA
Microchiller
Microchiller
Fori per collegamenti elettrici
Holes for electrical connections
Attacchi idraulici femmina ø 1”
Water connection female ø 1”
20
20 20
M6
20
20 20
