AERMEC AN R407C User Manual

35
AN 30 (°) - H
Out
In
352 900
1.000
140
477 466
200
155
50
Mod.
AB C D E FVT
030 °/H 334 352 650 900 300 155 7
030 A/HA 408 435 660 1.120 390 200 7
030 C 334 352 650 900 300 155 7
Attacchi idraulici maschio ø 1”
Water connection male ø 1”
Microchiller
Microchiller
Fori per collegamenti elettrici
Holes for electrical connections
F
A
Ø 10
C
E
B
D
352 900
1.000
70 140
338
200
155
Linea
del gas ø47
Gas line ø47
AN 30 C
435 1.120
1.014
In
Out
108 80
431,5
230 280
75
AN 30 A - HA
Attacchi idraulici femmina ø 1”
Water connection female ø 1”
20
20 20
M6
20
20 20
Microchiller
Microchiller
Linea del
liquido ø47
Liquid line ø47
