AERMEC AN R407C User Manual

36
AN 41 (°) - H
435 1.120
1.250
105
230 280
70
715 466
Out
In
Mod.
AB C D E FVT
041 °/H 408 435 660 1.120 320 185 7
041 A/HA 408 435 660 1.120 420 290 8
041 C 408 435 660 1.120 320 185 7
Attacchi idraulici maschio ø 1”
Water connection male ø 1”
Microchiller
Microchiller
Microchiller
Microchiller
Fori per collegamenti elettrici
Holes for electrical connections
F
A
Ø 10
C
E
B
D
435 1.120
1.250
145 70
420
230
280
70
Linea
del gas ø47
Gas line ø47
AN41 C
435 1.120
1.250
431,5
108
80 400
450
45
Out
In
AN 41 A - HA
Attacchi idraulici femmina ø 1”
Water connection female ø 1”
20
20 20
Microchiller
Microchiller
Linea del
liquido ø28
Liquid line ø28
M6
20
20 20
M8
30
20 20
8
VT7 VT8
