EN
1205. 6755517_02
13
TECHNICAL DATA MODELS POWER SUPPLY M.U. ANL100 ANL150
IP PROTECTION
IP Alls - - 24 24
SCROLL COMPRESSORS
Number / Circuit Alls - n°/n° 2 / 1 2 / 1
Resistance sump compressor Alls - n° x W 2 x 35 2 x 35
Capacity controls Alls - % 0 - 50 - 100 0 - 50 - 100
CHARGE
R410A refrigerant Alls - lib 28,0 35,3
Oil compressor Alls - lib 3,5 3,5
SYSTEM SIDE EXCHANGER
Quantity Alls - n° 1,00 1,00
Water content Alls - dm3 1,90 2,50
Hydraulic connection Alls - Ø 1"¼ 1"¼
Storage tank HA - n°/gl 1/26,42 1/26,42
EXPANSION VASSEL
Expansion vassel HP-HA - n°/gl 1/2,11 1/2,11
Expansion vassel calibration HP-HA - bar 1,50 1,50
PUMP
Imput power - - kW 0,75 1,50
Imput current
- 220-3-60 A
- 460-3-60 A 2,0 3,2
SAFETY VALVE
Safety valve - - n°/bar 1/6 1/6
FAN
Quantity - - n° 2 2
Air flow - - cfm 7775 7068
Input current - A 2 2
Input power - - kW 0,6 0,6
SOUND DATA
Sound pressure - - 76 77
Sound power - - 44 45
DIMENSION
Height - - in 57 57
Width - - in 30 30
Depth - - in 69 69
Weight
H - lib 650 710
HP - lib 690 756
HA - lib 800 866
HEATING (AHRI CONDITIONS)
COOLING (AHRI CONDITIONS)
SOUND POWER
-
SOUND PRESSURE
