AGFA CR 85-X Reference Manual

28
4451C EN 2013-04-30Introducing the CR 85-X
CR 85-X DIGITIZER
The display
The CR 85-X control panel has a backlit LCD display with 8 lines of 40
characters each. Its lay-out depends on the operating mode.
 In operator mode, the display has dedicated areas for specific information:
Left key
• To scroll backwards through multiple choices within a
field.
• To move the entry position in a numerical entry field
from right to left.
• To toggle between values in a field.
Right key
• To scroll forwards through multiple choices within a
field.
• To move the entry position in a numerical entry field
from left to right.
• To toggle between values in a field.
3
1
Set-up STATUS
OPERATION MODE
1ST MESSAGE
2nd Message
Patient_Last_Name Sub_Exam
Patient_Last_Name Sub_Exam
Patient_Last_Name Sub_Exam
Station Name ERROR
5
6
8.1
8.2
8.3
1
24
7
