Agilent Technologies 33500 Series Service Guide

136
Chapter 5 Block Diagram
Block Diagram
5
Waveform DAC
Elliptical Filter
Sync DAC
-7.96 dB
-15.91 dB
-23.87 dB
Offset DAC
Output Amp
Processor
Chan Out
Sync Out
Processor
Keyboard
Knob
DisplayUSB
GPIB
LAN
USB
RAM
ROM
Ref Out
Ref In
FPGA CLK WDAC1 CLK
WDAC2 CLK
Clock Generator
MOD In
FPGA
ARB1 SDRAM
ARB2 SDRAM
Trig
-23.87 dB
Output Relay
Meas
Over Voltage
Over Current
protect
Front Panel
Processor Board
Main Board
WDAC1 CLK
ADC
Channel 2
Offset DAC
FPGA
