The Front Panel at a Glance
Note: To get context-sensitive help on any front-panel key or menu softkey,
press and hold down that key.
1
3
4
5
6
7
8
9
10
11
12
13
14
15
{
{
16
1 USB Port
2 On/Off Switch
3 Channel 1 Summary Tab
4 Channel 2 Summary Tab
5 Waveform and Parameter Display Area
6 Menu Operation Softkeys
7 Waveforms/Parameters/Units Keys
8 Modulate/Sweep/Burst Keys
9 System Key
10 Numeric Keypad
11 Knob
12 Cursor Keys (Arrows)
13 Manual Trigger (Sweep and Burst only)
14 Sync Connector
15 Channel 1
16 Channel 2 (2-channel instrument only)
